Siemens siprotec 7SA6 User Manual

Technical Data
10-117SA6 Manual
C53000-G1176-C133-1
• Do not withdraw or insert individual modules or boards while the protective device
is energized. When handling the modules or the boards outside of the case, stand-
ards for components sensitive to electrostatic discharge (ESD) must be observed.
The modules, boards, and device are not endangered when the device is complete-
ly assembled.
10.1.9 Construction
Housing 7XP20
Dimensions see drawings, Section 10.20
Weight (mass) (max. complement) approx.
– 7SA61 in flush mounting housing:
size
1
/
3
4kg
size
1
/
2
6 kg (13.2 pounds)
size
1
/
1
10 kg (22.0 pounds)
in surface mounting housing:
size
1
/
3
6 kg (13.2 pounds)
size
1
/
2
11 kg (24.3 pounds)
size
1
/
1
19 kg (41.9 pounds)
– 7SA63 in flush mounting housing:
size
1
/
2
6 kg (13.2 pounds)
size
1
/
1
10 kg (22.0 pounds)
in surface mounting housing,
size
1
/
2
11 kg (24.3 pounds)
size
1
/
3
6 kg (13.2 pounds)
– 7SA64 in housing for detached operator panel:
size
1
/
2
6 kg (13.2 pounds)
size
1
/
1
10 kg (22.0 pounds)
– detached operator panel 2.5 kg
Degree of protection acc. IEC 60529
– for the device
in surface mounted case IP 51
in flush mounted case and with version with detached operator panel
front IP 51
rear IP 50
– for human safety IP 2x with closed protection cover
