Siemens siprotec 7SA6 User Manual

Functions
6-2897SA6 Manual
C53000-G1176-C133-1
6.21.5 Settings
Average
Calculation
Min/Max Values
Waveform Capture
Addr. Setting Title Setting Options Default Setting Comments
2801 DMD Interval 15 Min per., 1 Sub
15 Min per., 3 Subs
15 Min per., 15 Subs
30 Min per., 1 Sub.
60 Min per., 1 Sub.
60 Min per., 1 Sub. Demand Calculation Intervals
2802 DMD Sync.Time On the Hour
15 Min. after Hour
30 Min. after Hour
45 Min. after Hour
On the Hour Demand Synchronization Time
Addr. Setting Title Setting Options Default Setting Comments
2811 MinMax cycRESET NO
YES
YES Automatic Cyclic Reset Function
2812 MiMa RESET TIME 0..1439 min; Ø 0 min MinMax Reset Timer
2813 MiMa RESETCY-
CLE
1..365 day(s) 7 day(s) MinMax Reset Cycle Period
2814 Min-
MaxRES.START
1..365 Days 1 Days MinMax Start Reset Cycle in
Addr. Setting Title Setting Options Default Setting Comments
402A WAVEFORMTRIG-
GER
Save with Pickup
Save with TRIP
Start with TRIP
Save with Pickup Waveform Capture
403A WAVEFORM DATA Fault event
Power System fault
Fault event Scope of Waveform Data
410 MAX. LENGTH 0.30..5.00 sec 1.00 sec Max. length of a Waveform Cap-
ture Record
411 PRE. TRIG. TIME 0.05..0.50 sec 0.10 sec Captured Waveform Prior to
Trigger
412 POST REC. TIME 0.05..0.50 sec 0.10 sec Captured Waveform after Event
415 BinIn CAPT.TIME 0.10..5.00 sec; ∞ 0.50 sec Capture Time via Binary Input
