Configuration
5-57SA6 Manual
C53000-G1176-C133-1
The $5&RQWURO0RGH under address allows a total of four options. You can
determine whether the sequence of automatic reclosure cycles is defined by the fault
situation of the
pick-up
of the starting protection function(s) (only for three-pole
tripping) or by the type of
trip command
. The automatic reclosure can also operate
with
or
without
action time.
The 7ULS ZLWK7DFWLRQ or 7ULS ZL WKRXW7DFWLRQ command setting is
preferred when single-pole
or single/three-pole automatic reclosure cycles are
planned and are possible. In this case different dead times (for every interrupt cycle)
are possible after single-pole tripping and after three-pole tripping. The tripping
protection function determines the type of tripping: single-pole or three-pole. The dead
time is controlled dependent on this.
Using the3LFNXSZLWK
7DFWLRQ
or
3LFNXSZLWKRXW
7DFWLRQsetting,
different dead times can be set for the auto-reclosure cycles after single
, two and
three-phase
faults. The fault detection configuration of the protection functions at the
time the trip command disappears is decisive. This operating mode also enables the
dead times to be made dependent on the type of fault for three-pole interrupt cycles.
Tripping is always three-pole.
The 7ULS ZLWK7DFWLRQsetting provides an action time for every interrupt cycle.
This is started by the general starting signal (i. e. logic OR combination of all internal
and external start signals of all protection functions which are configured to start the
automatic reclosure function. If there is still no trip command when the action time
expired, the corresponding automatic reclosure cycle cannot be executed. See
section 6.12.1 for further explanations. For the time graded protection this setting is
recommended. If the protection function to operate with reclosure does not have a
general fault detection signal for starting the action times, select the setting 7ULS
ZLWKRXW7DFWLRQ.
In address )DXOW/RFDWRUfor fault location the user determines not only the
settings (QDEOHGand'LVDEOHG, but also the function that the fault distance is
directed via binary outputs as BCD-Code (4 bit units, 4 bit tens, 1 Bit hundreds as well
as “Data valid” (ZLWK%&'RXWSXW). The required number of output relays (FNo
to must therefore be available and allocated.
For the trip circuit supervision the number of trip circuits that shall be monitored is set
in address 7ULS&LUF6XSHUY with the following settings: 7ULSFLUFXLW,
7ULSFLUFXLWV or 7ULSFLUFXLWV if they are required (Disabled).
According to the order variant the device is provided with analog outputs (0 to 20 mA).
2 outputs can be located on Port B (Mounting location “B”), another 2 on Port D
(mounting location “D”). In address to the user can select which analog
values shall be output. Some measured values and the location of the fault are also
available.
5.1.1 Settings
Addr. Setting Title Setting Options Default Setting Comments
103 Grp Chge OPTION Disabled
Enabled
Disabled Setting Group Change Option
110 Trip mode 3pole only
1-/3pole
3pole only Trip mode
