Siemens siprotec 7SA6 User Manual

Configuration
5-6 7SA6 Manual
C53000-G1176-C133-1
114 Dis. PICKUP Z< (quadrilat.)
I> (overcurr.)
U/I
U/I/<phi>
Disabled
I> (overcurr.) Distance protection pickup
program
120 Power Swing Disabled
Enabled
Disabled Power Swing detection
121 Teleprot. Dist. PUTT (Z1B)
PUTT (Pickup)
POTT
Dir.Comp.Pickup
UNBLOCKING
BLOCKING
Rev. Interlock
Pilot wire comp
Disabled
Disabled Teleprotection for Distance prot.
122 DTT Direct Trip Disabled
Enabled
Disabled DTT Direct Transfer Trip
124 SOTF Overcurr. Disabled
Enabled
Disabled Instantaneous HighSpeed SOTF
Overcurrent
125 Weak Infeed Disabled
Enabled
Disabled Weak Infeed (Trip and/or Echo)
126 Back-Up O/C Disabled
TOC IEC
TOC ANSI
TOC IEC Backup overcurrent
130 Sens. Earth Flt Disabled
Enabled
Disabled Sensitive Earth Flt.(comp/ isol.
starp.)
131 Earth Fault O/C Disabled
TOC IEC
TOC ANSI
TOC Logarithm.
Definite Time
U0 inverse
Disabled Earth fault overcurrent
132 Teleprot. E/F Dir.Comp.Pickup
UNBLOCKING
BLOCKING
Disabled
Disabled Teleprotection for Earth fault
overcurr.
133 Auto Reclose Disabled
1 AR-cycle
2 AR-cycles
3 AR-cycles
4 AR-cycles
5 AR-cycles
6 AR-cycles
7 AR-cycles
8 AR-cycles
ADT
Disabled Auto-Reclose Function
134 AR control mode Pickup w/ Tact
Pickup w/o Tact
Trip w/ Tact
Trip w/o Tact
Pickup w/ Tact Auto-Reclose control mode
Addr. Setting Title Setting Options Default Setting Comments
