Functions
6-517SA6 Manual
C53000-G1176-C133-1
6.2.3.3 Settings
Note:
The indicated secondary current values and values of impedance for setting
ranges and default settings refer to I
N
= 1 A. For the nominal current 5 A the current
values are to be multiplied by 5. The values of impedance are divided by 5.
Addr. Setting Title Function Setting Options Default Setting
1201 FCT Distance Distance protection, general settings ON
OFF
ON
1202 Minimum Iph> Distance protection, general settings 0.10..4.00 A 0.10 A
1215 Paral.Line Comp Distance protection, general settings NO
YES
NO
1232 SOTF zone Distance protection, general settings with Pickup (non-
directional)
with Zone Z1B
Inactive
Inactive
1241 R load (Ø-E) Distance protection, general settings 0.10..250.00 Ohm;
∞
∞ Ohm
1242 ϕ load (Ø-E) Distance protection, general settings 20..60 ° 45 °
1243 R load (Ø-Ø) Distance protection, general settings 0.10..250.00 Ohm;
∞
∞ Ohm
1244 ϕ load (Ø-Ø) Distance protection, general settings 20..60 ° 45 °
1203 3I0> Threshold Distance protection, general settings 0.05..4.00 A 0.10 A
1204 3U0> Threshold Distance protection, general settings 1..100 V; ∞ 5 V
1205 3U0> COMP/
ISOL.
Distance protection, general settings 10..200 V 40 V
1206 T3I0 1PHAS Distance protection, general settings 0.00..0.50 sec 0.04 sec
1207A 3I0>/ Iphmax Distance protection, general settings 0.05..0.30 0.10
1220 PHASE
PREF.2phe
Distance protection, general settings L3 (L1) acyclic
L1 (L3) acyclic
L2 (L1) acyclic
L1 (L2) acyclic
L3 (L2) acyclic
L2 (L3) acyclic
L3 (L1) cyclic
L1 (L3) cyclic
all loops
L3 (L1) acyclic
1221A 2Ph-E faults Distance protection, general settings block leading ph-e
loop
block lagging ph-e
loop
all loops
only phase-phase
loops
only phase-earth
loops
block leading ph-e loop
