Siemens siprotec 7SA6 User Manual

Functions
6-2257SA6 Manual
C53000-G1176-C133-1
6.15.3 Settings
6.15.4 Information Overview
Addr. Setting Title Setting Options Default Setting Comments
3802 START Pickup
TRIP
Pickup Start fault locator with
3805 Paral.Line Comp NO
YES
NO Mutual coupling parall.line com-
pensation
3806 Load Compensat. NO
YES
NO Load Compensation
3811 Tmax OUTPUT
BCD
0.10..30.00 sec 0.30 sec Maximum output time via BCD
F.No. Alarm Comments
1114 Rpri = Flt Locator: primary RESISTANCE
1115 Xpri = Flt Locator: primary REACTANCE
1117 Rsec = Flt Locator: secondary RESISTANCE
1118 Xsec = Flt Locator: secondary REACTANCE
1119 dist = Flt Locator: Distance to fault
1120 d[%] = Flt Locator: Distance [%] to fault
1122 dist = Flt Locator: Distance to fault
1123 FL Loop L1E Fault Locator Loop L1E
1124 FL Loop L2E Fault Locator Loop L2E
1125 FL Loop L3E Fault Locator Loop L3E
1126 FL Loop L1L2 Fault Locator Loop L1L2
1127 FL Loop L2L3 Fault Locator Loop L2L3
1128 FL Loop L3L1 Fault Locator Loop L3L1
1132 Flt.Loc.invalid Fault location invalid
1133 Flt.Loc.ErrorK0 Fault locator setting error K0,angle(K0)
1143 BCD d[1%] BCD Fault location [1%]
1144 BCD d[2%] BCD Fault location [2%]
1145 BCD d[4%] BCD Fault location [4%]
1146 BCD d[8%] BCD Fault location [8%]
1147 BCD d[10%] BCD Fault location [10%]
1148 BCD d[20%] BCD Fault location [20%]
1149 BCD d[40%] BCD Fault location [40%]
1150 BCD d[80%] BCD Fault location [80%]
1151 BCD d[100%] BCD Fault location [100%]
