Siemens siprotec 7SA6 User Manual

Functions
6-257SA6 Manual
C53000-G1176-C133-1
6.1.3.2 Information Overview
1126 RM/RL ParalLine Power System Data 2 0.00..8.00 0.00
1127 XM/XL ParalLine Power System Data 2 0.00..8.00 0.00
1128 RATIO Par. Comp Power System Data 2 50..95 % 85 %
1130A PoleOpenCurrent Power System Data 2 0.05..1.00 A 0.10 A
1131A PoleOpenVoltage Power System Data 2 2..70 V 30 V
1132A SI Time all Cl. Power System Data 2 0.01..30.00 sec 0.05 sec
1134 Line Closure Power System Data 2 Manual Close BI only
Current OR Voltage or
Manual close BI
CBaux OR Current or
Manual close BI
Current flow or Manual
close BI
Manual Close BI only
1135 Reset Trip CMD Power System Data 2 with Pole Open Current
Threshold only
with CBaux AND Pole
Open Current
with Pole Open Current
Threshold only
1140A I-CTsat. Thres. Power System Data 2 0.2..50.0 A; ∞ 10.0 A
1150A SI Time Man.Cl Power System Data 2 0.01..30.00 sec 0.30 sec
1151 SYN.MAN.CL Power System Data 2 with Synchronism-check
without Synchronism-
check
NO
without Synchronism-check
1155 3pole coupling Power System Data 2 with Pickup
with Trip
with Trip
1156A Trip2phFlt Power System Data 2 3pole
1pole, leading phase
1pole, lagging phase
3pole
Addr. Setting Title Function Setting Options Default Setting
F.No. Alarm Comments
351 >CB Aux. L1 >Circuit breaker aux. contact: Pole L1
352 >CB Aux. L2 >Circuit breaker aux. contact: Pole L2
353 >CB Aux. L3 >Circuit breaker aux. contact: Pole L3
379 >CB 3p Closed >CB aux. contact 3pole Closed
380 >CB 3p Open >CB aux. contact 3pole Open
356 >Manual Close >Manual close signal
357 >Close Cmd. Blk >Block all Close commands from external
361 >FAIL:Feeder VT >Failure: Feeder VT (MCB tripped)
362 >FAIL:Bus VT >Failure: Busbar VT (MCB tripped)
