Siemens siprotec 7SA6 User Manual

Functions
6-1937SA6 Manual
C53000-G1176-C133-1
6.12.4 Information Overview
The most important information about automatic reclosure is briefly explained
insofar as it was not mentioned in the following lists or described in detail in the
preceding text.
“!%/.$5F\FOH” (F.No. ) to “!%/.Q$5” (F.No. )
The corresponding reclose cycle is blocked. If the blocking state already exists when
the automatic reclosure function is initiated, the blocked cycle is not executed and may
be skipped (if other cycles are permitted). The same applies if the automatic
reclosure function is started (running) but not busy with (inside) the cycle being
blocked. If the block signal of a cycle appears while this cycle is being executed (busy)
the automatic reclosure function is blocked dynamically; no further automatic
reclosures cycles are then executed.
“$5&\F=RQH5HO” (F.No. 2889) to “$5&\F=RQH5HO” (F.No. )
The automatic reclosure function is ready for the corresponding reclosure cycle. This
3490 4.AR Tdead3Trip 0.01..1800.00 sec; ∞ 0.50 sec Dead time after 3pole trip
3491 4.AR: Tdead EV. 0.01..1800.00 sec 1.20 sec Dead time after evolving fault
3492 4.AR: CB? CLOSE YES
NO
NO CB ready interrogation before
reclosing
3493 4.AR SynRequest YES
NO
NO Request for synchro-check after
3pole AR
3430 AR TRIP 3pole YES
NO
YES 3pole TRIP by AR
3431 DLC or RDT Without
Reduced Dead Time (RDT)
Dead Line Check (DLC)
Without Dead Line Check or Reduced
Dead Time
3438 T U-stable 0.10..30.00 sec 0.10 sec Supervision time for dead/ live
voltage
3440 U-live> 30..90 V 48 V Voltage threshold for live line or
bus
3441 U-dead< 2..70 V 30 V Voltage threshold for dead line
or bus
3420 AR w/ DIST. YES
NO
YES AR with distance protection
3421 AR w/ SOTF-O/C YES
NO
YES AR with switch-onto-fault over-
current
3422 AR w/ W/I YES
NO
YES AR with weak infeed tripping
3423 AR w/ EF-O/C YES
NO
YES AR with earth fault overcurrent
prot.
3424 AR w/ DTT YES
NO
YES AR with direct transfer trip
3425 AR w/ BackUpO/C YES
NO
YES AR with back-up overcurrent
Addr. Setting Title Setting Options Default Setting Comments
