Functions
6-100 7SA6 Manual
C53000-G1176-C133-1
6.4.3 Settings
6.4.4 Information Overview
Addr. Setting Title Function Setting Options Default Setting
2101 FCT Telep. Dis. Teleprotection for Dis-
tance prot.
ON
OFF
ON
2102 Type of Line Teleprotection for Dis-
tance prot.
Two Terminals
Three Terminals
Two Terminals
2103A Send Prolong. Teleprotection for Dis-
tance prot.
0.00..30.00 sec 0.05 sec
2107A Delay for alarm Teleprotection for Dis-
tance prot.
0.00..30.00 sec 10.00 sec
2108 Release Delay Teleprotection for Dis-
tance prot.
0.000..30.000
sec
0.000 sec
2109A TrBlk Wait Time Teleprotection for Dis-
tance prot.
0.00..30.00 sec;
∞
0.04 sec
2110A TrBlk BlockTime Teleprotection for Dis-
tance prot.
0.00..30.00 sec 0.05 sec
F.No. Alarm Comments
4001 >Dis.Telep. ON >Distance Teleprotection ON
4002 >Dis.Telep.OFF >Distance Teleprotection OFF
4003 >Dis.Telep. Blk >Distance Teleprotection BLOCK
4006 >DisTel Rec.Ch1 >Dis.Tele. Carrier RECEPTION Channel 1
4007 >Dis.T.RecCh1L1 >Dis.Tele.Carrier RECEPTION Channel 1,L1
4008 >Dis.T.RecCh1L2 >Dis.Tele.Carrier RECEPTION Channel 1,L2
4009 >Dis.T.RecCh1L3 >Dis.Tele.Carrier RECEPTION Channel 1,L3
4010 >Dis.T.Rec.Ch2 >Dis.Tele. Carrier RECEPTION Channel 2
4005 >Dis.RecFail >Dist. teleprotection: Carrier faulty
4030 >Dis.T.UB ub 1 >Dis.Tele. Unblocking: UNBLOCK Channel 1
4031 >Dis.T.UB bl 1 >Dis.Tele. Unblocking: BLOCK Channel 1
4032 >Dis.T.UB ub1L1 >Dis.Tele. Unblocking: UNBLOCK Ch. 1, L1
4033 >Dis.T.UB ub1L2 >Dis.Tele. Unblocking: UNBLOCK Ch. 1, L2
4034 >Dis.T.UB ub1L3 >Dis.Tele. Unblocking: UNBLOCK Ch. 1, L3
4035 >Dis.T.UB ub 2 >Dis.Tele. Unblocking: UNBLOCK Channel 2
4036 >Dis.T.UB bl 2 >Dis.Tele. Unblocking: BLOCK Channel 2
4040 >Dis.T.BlkEcho >Dis.Tele. BLOCK Echo Signal
4050 Dis.T.on/off BI Dis. Teleprotection ON/OFF via BI
4052 Dis.Telep. OFF Dis. Teleprotection is switched OFF
