Configuration
5-77SA6 Manual
C53000-G1176-C133-1
135 Synchro-Check Disabled
Enabled
Disabled Synchronism and Voltage Check
137 Overvoltage Disabled
Enabled
Disabled Overvoltage
138 Fault Locator Disabled
Enabled
with BCD-output
Enabled Fault Locator
139 BREAKER FAILURE Disabled
Enabled
Disabled Breaker Failure Protection
140 TripCirc.Superv Disabled
1 trip circuit
2 trip circuits
3 trip circuits
Disabled Trip Circuit Supervision
142 Ther. OVERLOAD Disabled
Enabled
Disabled Thermal overload protection
150 AnalogOutput B1 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Trip current Imax [primary]
Disabled Analog Output B1 (Port B)
151 AnalogOutput B2 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Trip current Imax [primary]
Disabled Analog Output B2 (Port B)
152 AnalogOutput D1 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Trip current Imax [primary]
Disabled Analog Output D1 (Port D)
153 AnalogOutput D2 Disabled
IL2 [%]
UL23 [%]
|P| [%]
|Q| [%]
Fault location d [%]
Fault location d [km]
Trip current Imax [primary]
Disabled Analog Output D2 (Port D)
Addr. Setting Title Setting Options Default Setting Comments
