Siemens siprotec 7SA6 User Manual

Functions
6-537SA6 Manual
C53000-G1176-C133-1
3707 Dis.Loop L1-E r Distance Loop L1E selected reverse
3708 Dis.Loop L2-E r Distance Loop L2E selected reverse
3709 Dis.Loop L3-E r Distance Loop L3E selected reverse
3710 Dis.Loop L1-2 r Distance Loop L12 selected reverse
3711 Dis.Loop L2-3 r Distance Loop L23 selected reverse
3712 Dis.Loop L3-1 r Distance Loop L31 selected reverse
3713 Dis.Loop L1E<-> Distance Loop L1E selected non-direct.
3714 Dis.Loop L2E<-> Distance Loop L2E selected non-direct.
3715 Dis.Loop L3E<-> Distance Loop L3E selected non-direct.
3716 Dis.Loop L12<-> Distance Loop L12 selected non-direct.
3717 Dis.Loop L23<-> Distance Loop L23 selected non-direct.
3718 Dis.Loop L31<-> Distance Loop L31 selected non-direct.
3719 Dis. forward Distance Pickup FORWARD
3720 Dis. reverse Distance Pickup REVERSE
3741 Dis. Z1 L1E Distance Pickup Z1, Loop L1E
3742 Dis. Z1 L2E Distance Pickup Z1, Loop L2E
3743 Dis. Z1 L3E Distance Pickup Z1, Loop L3E
3744 Dis. Z1 L12 Distance Pickup Z1, Loop L12
3745 Dis. Z1 L23 Distance Pickup Z1, Loop L23
3746 Dis. Z1 L31 Distance Pickup Z1, Loop L31
3747 Dis. Z1B L1E Distance Pickup Z1B, Loop L1E
3748 Dis. Z1B L2E Distance Pickup Z1B, Loop L2E
3749 Dis. Z1B L3E Distance Pickup Z1B, Loop L3E
3750 Dis. Z1B L12 Distance Pickup Z1B, Loop L12
3751 Dis. Z1B L23 Distance Pickup Z1B, Loop L23
3752 Dis. Z1B L31 Distance Pickup Z1B, Loop L31
3755 Dis. Pickup Z2 Distance Pickup Z2
3758 Dis. Pickup Z3 Distance Pickup Z3
3759 Dis. Pickup Z4 Distance Pickup Z4
3760 Dis. Pickup Z5 Distance Pickup Z5
3771 Dis.Time Out T1 DistanceTime Out T1
3774 Dis.Time Out T2 DistanceTime Out T2
3777 Dis.Time Out T3 DistanceTime Out T3
3778 Dis.Time Out T4 DistanceTime Out T4
3779 Dis.Time Out T5 DistanceTime Out T5
3780 Dis.TimeOut T1B DistanceTime Out T1B
F.No. Alarm Comments
