Siemens siprotec 7SA6 User Manual

Functions
6-12 7SA6 Manual
C53000-G1176-C133-1
204 Unom SECONDARY Power System Data 1 80..125 V 100 V
205 CT PRIMARY Power System Data 1 10..5000 A 1000 A
206 CT SECONDARY Power System Data 1 1A
5A
1A
207 SystemStarpoint Power System Data 1 Solid Earthed
Peterson-Coil earthed
Isolated
Solid Earthed
210 U4 transformer Power System Data 1 not connected
Udelta transformer
Usync transformer
Ux reference trans-
former
not connected
211 Uph / Udelta Power System Data 1 0.10..9.99 1.73
212 Usync connect. Power System Data 1 L1-E
L2-E
L3-E
L1-L2
L2-L3
L3-L1
L1-L2
214A ϕ Usync-Uline Power System Data 1 0..360 ° 0 °
215 U-line / Usync Power System Data 1 0.80..1.20 1.00
220 I4 transformer Power System Data 1 not connected
Neutral Current (of the
protected line)
Neutral Current of the
parallel line
Starpoint Curr. of
earthed power transf.
Neutral Current (of the protected
line)
221 I4/Iph CT Power System Data 1 0.010..5.000 1.000
230 Rated Frequency Power System Data 1 50 Hz
60 Hz
50 Hz
235 PHASE SEQ. Power System Data 1 L1 L2 L3
L1 L3 L2
L1 L2 L3
236 Distance Unit Power System Data 1 km
Miles
km
237 Format Z0/Z1 Power System Data 1 Zero seq. comp. fac-
tors RE/RL and XE/XL
Zero seq. comp. fac-
tor K0 and angle(K0)
Zero seq. comp. factors RE/RL
and XE/XL
239 T-CB close Power System Data 1 0.01..0.60 sec 0.06 sec
240A TMin TRIP CMD Power System Data 1 0.02..30.00 sec 0.10 sec
241A TMax CLOSE CMD Power System Data 1 0.01..30.00 sec 0.10 sec
242 T-CBtest-dead Power System Data 1 0.00..30.00 sec 0.10 sec
Addr. Setting Title Function Setting Options Default Setting
