Functions
6-118 7SA6 Manual
C53000-G1176-C133-1
3172 SOTF Op. Mode with Pickup (non-directional)
with Pickup and direction
with Pickup and
direction
Instantaneous mode after
SwitchOnToFault
3173 SOTF Time DELAY 0.00..30.00 sec 0.00 sec Trip time delay after SOTF
3110 Op. mode 3I0>>> Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode
3111 3I0>>> 0.50..25.00 A 4.00 A 3I0>>> Pickup
3112 T 3I0>>> 0.00..30.00 sec; ∞ 0.30 sec T 3I0>>> Time delay
3113 3I0>>> Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
3114 3I0>>>SOTF-Trip NO
YES
NO Instantaneous trip after Switch-
OnToFault
3115 3I0>>>InrushBlk NO
YES
NO Inrush Blocking
3120 Op. mode 3I0>> Forward
Reverse
Non-Directional
Inactive
Inactive Operating mode
3121 3I0>> 0.20..25.00 A 2.00 A 3I0>> Pickup
3122 T 3I0>> 0.00..30.00 sec; ∞ 0.60 sec T 3I0>> Time Delay
3123 3I0>> Telep/BI NO
YES
NO Instantaneous trip via Teleprot./
BI
