Functions
6-2497SA6 Manual
C53000-G1176-C133-1
for analog output 1 at mounting location “D” (Port D1):
Address P$' value in % to be indicated at 20 mA
Address 0,19$/8(' the minimum value permitted
for analog output 2 at mounting location “D” (Port D2):
Address P$' value in % to be indicated at 20 mA
Address 0,19$/8(' the minimum value permitted
The maximum value is 22.0 mA. If it is exceeded (value outside of the maximum
permissible range), then a value of 22.5 mA is output.
Example:
The phase current I
L2
is output as analog output 1 at mounting location “B”. The
operational nominal current should correspond to 10 mA output, which means that
20 mA correspond to a rate of 200 %. Values below 4 mA are not valid.
Settings:
Address P$% %,
Address 0,19$/8(% = mA.
Fault Location For the fault location the conversion factor, i. e. the value to be output, is also set to
20 mA. Dependening on whether the fault location should be output in per cent of the
line length or in length unit, set the following:
For analog output 1 at mounting location “B” (Port B1):
Address P$% value in % to be indicated at 20 mA
or
Address or P$% value in kilometres or miles that is
to be indicated at 20 mA.
For analog output 2 at mounting location “B” (Port B2):
Address P$% value in % to be indicated at 20 mA
or
Address or P$% value in kilometres or miles that
is required to be indicated at 20 mA.
For analog output 1 at mounting location “D” (Port D1):
Address P$' value in % to be indicated at 20 mA
or
Address or P$' value in kilometres or miles that
is required to be indicated at 20 mA.
For analog output 2 at mounting location “D” (Port D2):
Address P$' the value in % that is required to be indicated at
20 mA
or
Address or P$' value in kilometres or miles
to be indicated at 20 mA.
Set in Addresses 1(*9$/8(%, 1(*9$/8(%, 1(*
9$/8(' or 1(*9$/8(' which output value is to be indicated in case
the fault location is negative (fault in reverse direction). In addresses 29(5)/2:
%, 29(5)/2:%, 29(5)/2:' or 29(5)/2:'
the value of the numerical overflow (fault outside the maximum permissible range) is
set.
