Siemens siprotec 7SA6 User Manual

Functions
6-2677SA6 Manual
C53000-G1176-C133-1
Trip Command
Supervision
167 Fail U balance Failure: Voltage Balance
169 VT FuseFail>10s VT Fuse Failure (alarm >10s)
170 VT FuseFail VT Fuse Failure (alarm instantaneous)
171 Fail Ph. Seq. Failure: Phase Sequence
195 Fail Conductor Failure: Broken Conductor
196 Fuse Fail M.OFF Fuse Fail Monitor is switched OFF
197 MeasSup OFF Measurement Supervision is switched OFF
F.No. Alarm Comments
F.No. Alarm Comments
6854 >TripC1 TripRel >Trip circuit superv. 1: Trip Relay
6855 >TripC1 Bkr.Rel >Trip circuit superv. 1: Breaker Relay
6856 >TripC2 TripRel >Trip circuit superv. 2: Trip Relay
6857 >TripC2 Bkr.Rel >Trip circuit superv. 2: Breaker Relay
6858 >TripC3 TripRel >Trip circuit superv. 3: Trip Relay
6859 >TripC3 Bkr.Rel >Trip circuit superv. 3: Breaker Relay
6861 TripC OFF Trip circuit supervision OFF
6865 FAIL: Trip cir. Failure Trip Circuit
6866 TripC1 ProgFAIL TripC1 blocked: Binary input is not set
6867 TripC2 ProgFAIL TripC2 blocked: Binary input is not set
6868 TripC3 ProgFAIL TripC3 blocked: Binary input is not set
