Siemens siprotec 7SA6 User Manual

Technical Data
10-477SA6 Manual
C53000-G1176-C133-1
Detached
Operator Panel
Figure 10-15 Dimensions of a detached operator panel for a 7SA6 device
n
246.2 (9.69)
266 (10.47)
2 (0.08)
29.5 27
Mounting Plate
225 (8.86)
220 (8.66)
Side View Rear View
Panel Cut-Out
68-pin Connection Cable
to Device
Length 2.2 m (0.09)
221
+ 2
(8.70
+ 0.08
)
5 (0.20)
6 (0.24)
255.8
±
0.3
(10.07
± 0.01
)
180
± 0.5
(7.07
± 0.02
)
206.5
± 0.3
(8.13
± 0.01
)
247.2
+ 1
(9.73
+ 0.04
)
(1.16)
(1.06)
or M4
4.3 (0.17)
13.2 (0.52)
7.3 (0.29)
