Appendix
A-10 7SA6 Manual
C53000-G1176-C133-1
Interface Cable An interface cable is necessary for communication between the SIPROTEC device
and a PC. Requirements for the computer are Windows 95 or Windows NT4 and the
operating software DIGSI
®
4
Operating Software
DIGSI
®
4
Software for setting and operating SIPROTEC
®
4 devices
Graphical Analysis
Program DIGRA
Software for graphical visualization, analysis and evaluation of fault data. Option pack-
age of the complete version of DIGSI
®
4
Display Editor Software for creating basic and power system control pictures. Option package
of the complete version of DIGSI
®
4
Graphic Tools Graphical Software to aid in the setting of characteristic curves and provide zone dia-
grams for overcurrent and distance protective devices. Option package of the com-
plete version of DIGSI
®
4.
DIGSI REMOTE 4 Software for remote operating protective devices via a modem (and possibly a star
connector) using DIGSI
®
4. (Option package of the complete version of DIGSI
®
4.
SIMATIC CFC 4 Software for graphical setting interlocking (latching) control conditions and creating
additional function is SIPROTEC 4 devices. Option package for the complete version
of DIGSI
®
4.
Interface Cable between PC or SIPROTEC device Order No.
Cable with 9-pin male/female connections 7XV5100-4
Operating Software DIGSI
®
4
Order No.
DIGSI
®
4, basic version with license for 10
computers
7XS5400-0AA00
DIGSI
®
4, complete version with all option packages
7XS5402-0AA0
Graphical Analysis Program DIGRA
®
Order No.
Full version with license for 10 machines 7XS5410-0AA0
Display Editor 4 Order No.
Full version with license for 10 machines 7XS5420-0AA0
Graphic Tools 4 Order No.
Full version with license for 10 machines 7XS5430-0AA0
DIGSI REMOTE 4 Order No.
Full version with license for 10 machines 7XS5440-1AA0
SIMATIC CFC 4 Order No.
Full version with license for 10 machines 7XS5450-0AA0
