Appendix
A-44 7SA6 Manual
C53000-G1176-C133-1
Table A-4 Further binary input presettings for7SA6*1 and 7SA6*2
Binary Input LCD Text Function No. Remarks
BI6 >TripC1 TripRel 6854 Trip Circuit Supervision (TripCirc.Su-
perv), Circuit 1, H–active
BI8 >CB 3p Open
>CB1 3p Open
Breaker (open)
2
)
380
411
—
Circuit breaker position 3pole Open,
H–active
BI9 >CB 3p Closed
>CB1 3p Closed
Breaker (closed)
2
)
397
410
—
Circuit breaker position 3pole
Closed, H–active
BI10 Disc.Swit.(open)
2
) — Disconnect switch Open, H–active
2
)
BI11 Disc.Swit. (closed)
2
) — Disconnect switch Closed,
H–active
2
)
BI12 EarthSwit (open)
2
) — Earth switch open, H–active
2
)
BI13 EarthSwit (closed)
2
) — Earth switch closed, H–active
2
)
BI16 >Door open — High voltage system, Door open,
H–active
2
)
(further) — — no presetting
2
)
1
) only devices without power relays
2
) only devices with power relays
Table A-5 Further binary output presettings for all ordering variants
Binary
Output
LCD Text Function
No.
Remarks
BO1 Relay PICKUP 0501 Device (general) pickup
BO5 Alarm Sum Event 0160 Alarm Summary Event
Table A-6 Further binary output presettings for 7SA610*–*A/E/J
Binary
Output
LCD Text Function
No.
Remarks
BO3 AR CLOSE Cmd. 2851 Automatic reclosure close command
3
)
BO7 Dis.T.SEND 4056 Distance protection teleprotection send
signal
