Appendix

B-21

7SA6 Manual

C53000-G1176-C133-1

5017 NEG VALUE (B2) AnalogOutputs 19.00..22.50 mA 19.84 mA Output value (B2) for negative values

5018 OVERFLOW (B2) AnalogOutputs 19.00..22.50 mA 22.50 mA Output value (B2) for overflow

5019 Tmax OUTPUT(B2) AnalogOutputs 0.10..30.00 sec; ∞ 5.00 sec Maximum output time (B2)

5021 20 mA (D1) = AnalogOutputs 10.0..1000.0 % 200.0 % 20 mA (D1) correspond to

5022 20 mA (D1) = AnalogOutputs 10..100000 A 20000 A 20 mA (D1) correspond to

5023 20 mA (D1) = AnalogOutputs 1.0..1000.0 km 50.0 km 20 mA (D1) correspond to

5024 20 mA (D1) = AnalogOutputs 1.0..1000.0 Miles 50.0 Miles 20 mA (D1) correspond to

5026 MIN VALUE (D1) AnalogOutputs 0.0..5.0 mA 4.0 mA Output value (D1) valid from

5027 NEG VALUE (D1) AnalogOutputs 19.00..22.50 mA 19.84 mA Output value (D1) for negative values

5028 OVERFLOW (D1) AnalogOutputs 19.00..22.50 mA 22.50 mA Output value (D1) for overflow

5029 Tmax OUTPUT(D1) AnalogOutputs 0.10..30.00 sec; ∞ 5.00 sec Maximum output time (D1)

5031 20 mA (D2) = AnalogOutputs 10.0..1000.0 % 200.0 % 20 mA (D2) correspond to

5032 20 mA (D2) = AnalogOutputs 10..100000 A 20000 A 20 mA (D2) correspond to

5033 20 mA (D2) = AnalogOutputs 1.0..1000.0 km 50.0 km 20 mA (D2) correspond to

5034 20 mA (D2) = AnalogOutputs 1.0..1000.0 Miles 50.0 Miles 20 mA (D2) correspond to

5036 MIN VALUE (D2) AnalogOutputs 0.0..5.0 mA 4.0 mA Output value (D2) valid from

5037 NEG VALUE (D2) AnalogOutputs 19.00..22.50 mA 19.84 mA Output value (D2) for negative values

5038 OVERFLOW (D2) AnalogOutputs 19.00..22.50 mA 22.50 mA Output value (D2) for overflow

5039 Tmax OUTPUT(D2) AnalogOutputs 0.10..30.00 sec; ∞ 5.00 sec Maximum output time (D2)

Addr. Setting Title Function Setting Options Default Setting Comments

Note:

Depending on the version and the variant ordered some addresses are not used or have different default settings. The setting ranges

and presettings listed in the table refer to a nominal current value I

= 1 A. For a secondary nominal current value I

= 5 A the current

values are to be multiplied by 5. For setting primary values the transformation ratio of the transformer also must be taken into conside-

ration. Settings specified with an "A" can only be changed with DIGSI

4 under "Additional Settings".
