Cabinet Modules
5.1 Line Connection Modules
Cabinet Modules NEMA
144 Manual, 04/2014, A5E03586450A
Other options
Component
Option
UL listing per UL 508A
U90
cUL listing for Canada per UL 508A
U91
5.1.4
Technical specifications
Table 5- 9 Technical specifications for Line Connection Modules, 380 to 480 V 3 ph. AC, part I
Order no.
6SL3700-
0LE32-
5AU3
0LE34-
0AU3
0LE36-
3AU3
0LE38-
0AU3
0LE41-
0AU3
Infeed/regenerative feedback current
- Rated current I
N E
A
250
380
600
770
1000
Supply voltages
- Line voltage
- Line frequency
V
ACrms
Hz
3 AC 380 -10 % to 3 AC 480 +10 % (-15 % < 1 min)
47 to 63 Hz
230 V AC current demand
1)
- Starting current
- Holding current
A
A
3.6
0.04
3.6
0.04
3.6
0.04
10.8
0.12
0.5
0.06
Power loss, max.
2)
with 50 Hz 400 V
- Option L42/L44
- Option L43
with 60 Hz 460 V
- Option L42/L44
- Option L43
kW
kW
kW
kW
0.115
--
0.115
--
0.19
--
0.19
--
0.31
0.675
0.31
0.675
0.39
0.74
0.39
0.74
0.18
--
0.18
--
Fan
- 230 V AC current demand
- Cooling air requirement
- Sound pressure level L
PA
(1 m) with 50/60 Hz
A
cfm
m
3
/s
dB(A)
--
--
--
--
--
--
--
--
--
--
--
--
--
--
--
1.07
763
0.36
68/70
Line connection L1, L2, L3
- Max. conductor cross-section (IEC)
- Max. conductor cross-section (NEC, CEC)
mm
2
AWG/MCM
4)
5)
2 x 120
2 x 250
4)
5)
2 x 120
2 x 250
4)
6)
2 x 300
2 x 600
4)
6)
3 x 240
3 x 500
5/M12 +
4/M16
8 x 240
8 x 500
PE/GND connection
- Busbar cross-section
- Max. conductor cross-section (IEC)
- Max. conductor cross-section (NEC, CEC)
mm
2
mm
2
AWG/MCM
PE busbar
600
240
500
Degree of protection (standard model)
IP20
IP20
IP20
IP20
IP20
Dimensions
(standard model, IP20)
- width
- height
3)
- depth
- width
- height
3)
- depth
inch
inch
inch
mm
mm
mm
23.6
86.6
23.6
600
2200
600
23.6
86.6
23.6
600
2200
600
23.6
86.6
23.6
600
2200
600
23.6
86.6
23.6
600
2200
600
23.6
86.6
23.6
600
2200
600
