Options
8.35 L87, insulation monitoring
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
473
Dimensions of the braking resistors
Table 8- 57 Dimensions of the braking resistors
25 kW resistor
(option L61/L64)
50 kW resistor
(option L62/L65)
Figure 8-47 Duty cycle for braking resistors
L87, insulation monitoring
Availability of option
This option is available for the following S120 Cabinet Modules:
● Line Connection Modules
