Mounting grid arrangement in the cabinet

The area for connecting the Motor Modules in the cabinet is divided into three grid widths:

● 4" (100 mm)

● 8" (200 mm)

● 12" (300 mm)

The table below shows the grid width assigned to the various Motor Modules.

Table 5- 26 The assignment of the Motor Modules according to grid width

Grid width

Assignment of Motor Modules (see the section "Technical specifications")

4" (100 mm)

9 ... 30 A Motor Modules

8" (200 mm)

45 to 85 A Motor Modules

12" (300 mm)

132 A Motor Module

Note

Available space in the Booksize base cabinets

The space available for the Motor Modules in the Booksize base cabinets is deter

mined by

taking the actual space and subtracting a clearance of 8" (200

mm).

5.5.2

Interface description

5.5.2.1

General information

This section describes only those interfaces in the cabinet unit that require additional

connection work by the customer. All other interfaces are pre-wired at the factory and are not

designed for customer connections.

Note

Additional information

All connections to be established on the plant side as well as the interfaces for integration

into the plant control s

ystem are described in the circuit diagrams and terminal diagrams on

the customer DVD supplied with the device.
