8.17 K82, terminal module for activating safety functions "Safe Torque Off" and "Safe Stop 1"
Cabinet Modules NEMA
392 Manual, 04/2014, A5E03586450A
8.17
K82, terminal module for activating safety functions "Safe Torque
Off" and "Safe Stop 1"
Availability of option
This option is available for the following S120 Cabinet Modules:
● Booksize Cabinet Kits
● Motor Modules in chassis format
Description
The option K82 (terminal module for activating "Safe Torque Off" and "Safe STOP 1") is
used for isolated activation via a variable control voltage range of the safety functions
already present in the standard, which can also be used without option K82.
The following Safety Integrated functions (terms according to IEC 61800-5-2) can be
controlled using option K82:
● Safe Torque Off (STO)
● Safe Stop 1 (SS1, time-controlled)
Note
Standard requirements
The integrated safety functions, starting from the Safety Integrated (SI) input terminals of the
SINAMICS components (Control Unit, Motor Module), satisfy the requirements according to
EN
61800-5-2, EN 60204-1 and DIN EN ISO 13849-1 category 3 (formerly EN 954-1), as
well as the requirements for Performance Level (PL) d and IEC 61508 SIL2.
In combination with the option K82, the requirements specified in EN
61800-5-2, EN
60204
-1, as well as in DIN EN ISO 13849-1 category 3 (formerly EN 954-1) are satisfied for
Performance Level (PL) d and IEC 61508 SIL2.
Note
Safety Integrated Function Manual
Detailed and comprehensive instructions and information for the Safety Integrated functions
can be found in the associated Function Manua
l. This manual is available as additional
documentation on the customer DVD supplied with the device.
