Mechanical installation
3.3 Installation
Cabinet Modules NEMA
58 Manual, 04/2014, A5E03586450A
Connection to the foundation
Preparatory steps
● If possible, allow unimpeded access to the holes at the bottom of the cabinet units by
removing the protective covers when carrying out installation work.
Connection to the foundation
Four holes for M12 screws are provided on each cabinet panel to secure the cabinet to the
foundation. The fixing dimensions are specified in the dimension drawings.
Every cabinet panel must be attached to the ground using at least 2 opposing attachment
points (1 screw each in the front and rear part of the cabinet panel).
If this is not possible for reasons of accessibility, then the attachment points of the adjacent
cabinet panels must be correspondingly raised.
Generally, as many attachment points as possible should be used.
Note
Additional information
Additional dimensions can be found in the relevant dimension drawings on the customer
DVD supplied with the device.
