Options
8.20 K90, Control Unit CU320-2 DP
Cabinet Modules NEMA
416 Manual, 04/2014, A5E03586450A
STARTER setup is possible with native Windows versions with Asian languages only if the
Windows XP or Windows 7 software is an MUI version.
Acrobat Reader V5.0 or higher is required to open the function diagrams in the online help.
Note
Requirements in conjunction with STEP 7
If STARTER is used in combination with other STEP 7 components, the requirements for
these S7 components apply.
Additional system requirements for installing a CompactFlash card reader
● Free USB connection
● CD-ROM drive (for installing the driver for the card reader)
Once a card reader has been connected and successfully installed, the data on the memory
card can be accessed in the same way as data stored on other PC storage media (e.g.,
access to hard disk, memory stick, etc.). To access its data, the memory card must first be
removed from the Control Unit CU320-2 and inserted in the card reader connected to the
PC.
The actual procedure for accessing the memory card data depends on the operating system
used.
Saving the memory card parameter settings
Following commissioning, it is advisable to back up the data on the memory card to an
external storage medium (hard disk, data carrier, etc.).
To do this, the memory card is read out via a card reader connected to a PC. Ensure that all
the files and directories are stored in the same form as on the memory card.
If necessary, the device status following commissioning of the drive can be restored by
importing the backed up data to the memory card.
Note
Possible plant shutdown by withdrawing or inserting the memory card during operation
If the memory card is withdrawn or inserted during operation, data can be lost, possibly
resulting in a plant shutdown.
Only pull and plug the memory card when the Control Unit is disconnected from the
supply.
