Options
8.33 L55, cabinet anti-condensation heating
Cabinet Modules NEMA
460 Manual, 04/2014, A5E03586450A
L55, cabinet anti-condensation heating
Availability of option
This option is available for the following S120 Cabinet Modules:
● Line Connection Modules
● Basic Line Modules
● Smart Line Modules
● Active Line Modules
● Booksize base cabinets
● Motor Modules in chassis format
● Auxiliary Power Supply Modules
The cabinet anti-condensation heating can be used at low ambient temperatures and high
levels of humidity to prevent the formation of condensation.
A 100 W heater (-E240) is used for 15.8 inch (400 mm) and 23.6 inch (600 mm) cabinets.
Two 100 W heaters (-E240, -E241) are used for cabinet widths of 31.5 inch (800 mm) or
higher.
The supply voltage (110 to 230 V AC) must be provided externally and protected with a fuse
with max. 16 A.
X240 connection for cabinet anti-condensation heating
Table 8- 51 Terminal block X240
110 to 230 V AC voltage supply
Current demand:
- min.: approx. 0.43 A (for 230 V AC, 100 W)
- max.: approx. 1.8 A (for 110 V AC, 200 W)
2 N
3 PE Protective conductor
Max. connectable cross-section #12 AWG (4 mm²)
Risk of death due to hazardous electrical voltage from an external auxiliary supply
When an external supply voltage for the cabinet anti-condensation heating is connected,
hazardous voltages continue to be present in the cabinet unit even when the main switch is
switched off. Death or serious injury can result when live parts are touched.
• Observe the general safety instructions when working on the device.
