Options
8.20 K90, Control Unit CU320-2 DP
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
417
Slot for the memory card
Slot for the memory card
Figure 8-29 Slot for the memory card
Note
Insertion direction of the memory card
Only insert the memory card as shown in the figure above (arrow at top right).
Note
Possible data loss when returning the Control Unit with memory card
When a defective Control Unit is returned, the data on the memory card (parameters,
firmware, licenses, etc.) could be lost during repair and testing.
Do not return the memory card with the Control Unit, but keep it in a safe place so that it
can be inserted in the replacement unit.
