System overview
2.10 System data
Cabinet Modules NEMA
36 Manual, 04/2014, A5E03586450A
2.10
System data
General technical system data
General data
Line voltages and power ranges
380 to 480 V 3 ph. AC, ±10 % (-15 % < 1 min), 5 ... 1150 HP (4.8 ... 800 kW)
1)
500 to 690 V 3 ph. AC, ±10 % (-15 % < 1 min), 75 to 1250 HP (55 to 1200 kW)
1)
Electrical network configurations
Line supplies grounded at the neutral point (TN/TT systems) or ungrounded line
supplies (IT systems)
Line frequency
47 ... 63 Hz
Output frequency
Vector control: 0 ... 600 Hz
Servo control: 0 ... 650 Hz
V/f control: 0 ... 650 Hz
Line power factor fundamental
factor
Basic Line Modules:
> 0,96
Smart Line Modules:
> 0,96
Active Line Modules:
variable (set in factory to cos
φ =1)
Efficiency
> 99,0 %
> 98,5 %
> 97,5 %
Control method
Servo control, vector control with and without encoder or V/f control
Fixed speeds
15 fixed speeds plus 1 minimum speed, programmable
Skipped speed ranges
4, configurable
Braking operation
With regenerative feedback or by additional braking modules and braking resistors
Degree of protection
IP20, IP21, IP23 (NEMA1 filtered), IP43 and IP54 (NEMA12 ventilated)
(with option M26 and M27, side panels on the right or left)
Safety class
Safety class I according to IEC 61800-5-1
Overvoltage category
III according to IEC 61800-5-1
Degree of pollution
II according to IEC 61800-5-1
Cooling method
Forced air cooling AF according to IEC 60146
Shock protection
BGV A 3 according to EN 50274
Cabinet system
Rittal TS 8, doors with double-bit key, tripartite base plates for cable inlet
Paint finish
RAL 7035 (indoor requirements)
1)
Output data in the basic version, performance enhancement possible with parallel connection.
Compliance with standards
Standards
EN 50274, IEC 60146-1, IEC 60204-1, IEC 60529, IEC 61800-2, IEC 61800-3,
IEC 61800-5-1
CE marking
- EMC Directive No. 2004/108/EC
- Low Voltage Directive No. 2006/95/EC
- Machinery Directive No. 2006/42/EC for Functional Safety
RFI suppression
According to EMC product standard for variable-speed drives IEC 61800-3,
2nd environment (1st environment on request)
UL certificate
(only up to 600 V 3AC)
According to UL 508A (Option U90) or cUL 508A (Option U91)
