Options
8.37 M07, cable marshalling compartment 8" (200 mm) high, RAL 7035
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
477
Connection to the foundation
To connect the cable marshalling compartment to the foundation, four holes for M12 screws
are provided. These are in line with the holes in the cabinet. The fixing dimensions are
specified in the dimension drawings.
Connection for side-by-side installation of cabinet units
The individual bases are not connected for cabinet units installed in a side-by-side
configuration. The connection from the base to the cabinet and between the cabinet units
ensures sufficient stability.
Note
In transport units, the base covers inside the transport unit are only secured at the bottom
and are folded down
parallel to the ground.
M07, cable marshalling compartment 8" (200 mm) high, RAL 7035
Availability of option
This option is available for the following S120 Cabinet Modules:
● Line Connection Modules
● Basic Line Modules
● Smart Line Modules
● Active Line Modules
● Booksize base cabinets
● Motor Modules in chassis format
● Auxiliary Power Supply Modules
Because it is raised 8" (200 mm), the supplementary cable marshalling compartment made
of stable sheet steel allows for greater bending radii for cables (cable inlet from below) and
cable routing within the cable marshalling compartment.
The cable marshalling compartment comes completely assembled and has color RAL 7035
as standard.
cable marshalling compartment increases the cabinet height by 8" (200 mm).
