7.11 LEDs on the SMC10 Sensor Module
Cabinet Modules NEMA
344 Manual, 04/2014, A5E03586450A
LEDs on the SMC10 Sensor Module
Table 7- 20 Meaning of the LEDs on the SMC10 Sensor Module
RDY
(READY)
--- Off The electronics power supply is missing or lies outside the permissible tolerance
Green Continu-
The component is ready for operation and cyclic DRIVE-CLiQ communication is
Orange Continu-
DRIVE-CLiQ communication is being established.
Red Continu-
ous light
At least one fault is present in this component.
Note:
LED is activated irrespective of any reconfiguring of the corresponding messages.
Green/
Red
Flashing
Firmware is being downloaded.
Flashing
Firmware download is being completed.
Green/
Orange
Or Red/
Flashing
2 Hz
Detection of the component via LED is activated (p0144).
Note:
The two options depend on the LED status when component detection is activated
LEDs on the SMC20 Sensor Module
Table 7- 21 Meaning of the LEDs on the SMC20 Sensor Module
RDY
(READY)
--- Off The electronics power supply is missing or lies outside the permissible tolerance
Green Continu-
ous light
The component is ready for operation and cyclic DRIVE-CLiQ communication is
taking place.
Orange Continu-
DRIVE-CLiQ communication is being established.
Red Continu-
ous light
At least one fault is present in this component.
LED is activated irrespective of any reconfiguring of the corresponding messages.
Green/
Red
Flashing
Firmware is being downloaded.
Flashing
Firmware download is being completed.
Green/
Orange
or
Red/
Flashing Detection of the component via LED is activated (p0144).
The two options depend on the LED status when component detection is activated
via p0144 = 1.
