System overview
2.8 System structure
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
33
2.8
System structure
Line Modules are coupled with the various Motor Modules using prefabricated DC busbar
sets with different current load ratings.
All standard busbars, as well as electronics components, are protected against
environmental influences. This is achieved through the use of nickel-plated copper bars and
painted modules throughout.
An auxiliary power supply system spanning the individual Cabinet Modules supplies the
required auxiliary voltages for the equipment fans and the 24 V DC loads.
Communication between the Control Unit, Line Modules, and Motor Modules and other
active SINAMICS components takes place via DRIVE-CLiQ connections.
DRIVE-CLiQ is an internal serial interface of the drive that enables fast and easy
configuration of the complete drive configuration with prefabricated cables in varying lengths.
As an option, Cabinet Modules can be delivered in pre-configured transport units with a total
width of up to 94.5 inches (2400 mm) each. This option is recommended in particular for Line
Modules together with Line Connection Modules because the Line Connection Module must
be equipped with a pre-charging DC link or line reactors (depending on the type of Line
Module) in this case, in addition to the electrical interface (mounted on a busbar). Transport
units enable the various devices to be quickly and easily assembled on-site.
2.9
Overview of options
Table 2- 2 Overview of options
Option code
Brief description of option
D02
Customer documentation (circuit diagram, terminal diagram, layout diagram) in DXF format
D14
Draft of customer documentation
D58
Documentation language: English/French
D60 Documentation language: English/Spanish
D76
Additional manual, English
D77 Additional manual, French
D78
Additional manual, Spanish
F03
Visual acceptance
F71
Function test with no motor connected (with the customer present)
F72
Function test with no motor connected (without the customer present)
F74
Function test with test bay motor with no load (without the customer present)
F75
Function test with test bay motor with no load (with the customer present)
F76
Insulation test (without the customer present)
F77
Insulation test (with the customer present)
F97
Customer-specific acceptance inspections (on request)
G20
CBC10 Communication Board
G33
CBE20 Communication Board
G51
1 TM150 Temperature Sensor Module
