Options
8.24 L10, dv/dt filter plus Voltage Peak Limiter
Cabinet Modules NEMA
440 Manual, 04/2014, A5E03586450A
Motor connection
If the L08 / L09 option is used with Booksize Cabinet Kits, the motor cables are connected to
terminal block -X1.
Table 8- 41 Maximum conductor cross-section when using motor reactors for Booksize Cabinet Kits
Order no.
6SL3720-
Power in kW (HP)
Maximum conductor cross-
section in mm² (AWG)
1TE21-0AU3
4.8 (5)
6 (10)
1TE21-8AU3
9.7 (10)
6 (10)
1TE23-0AU3
16 (20)
6 (10)
1TE24-5AU3 24 (30) 16 (6)
1TE26-0AU3
32 (40)
16 (6)
1TE28-5AU3
46 (60)
35 (2)
1TE31-3AU3
71 (100)
95 (4/0)
8.24
L10, dv/dt filter plus Voltage Peak Limiter
Availability of option
This option is available for the following S120 Cabinet Modules:
● Motor Modules in chassis format
Description
The dv/dt filter plus voltage peak limiter comprises two components: the dv/dt reactor and
the voltage-limiting network (voltage peak limiter), which limits the voltage peaks to the level
of the DC link voltage and returns energy to the DC link.
The dv/dt filters plus voltage peak limiter must be used for motors for which the dielectric
strength of the insulation system is unknown or insufficient. Standard motors of the 1LA5,
1LA6, and 1LA8 series only require them at supply voltages > 500 V + 10 %.
The dv/dt filter plus voltage peak limiter limits the voltage gradient to values < 500 V/µs and
the typical voltage peaks to the values below (for motor cable lengths of < 980 ft (300 m) for
frame sizes FX, GX, HX or < 490 ft (150 m) for frame size JX):
< 1000 V at U
line
< 575 V
< 1250 V at 660 V < U
line
< 690 V.
Option L10 is installed in an additional cabinet with a width of 23.6 inches (600 mm) that is
located on the right-hand side of the Motor Module.
