Cabinet Modules
5.2 Basic Line Modules
Cabinet Modules NEMA
152 Manual, 04/2014, A5E03586450A
5.2
Basic Line Modules
5.2.1
Description
Note
Additional information
Refer t
o the layout diagrams (AO) and circuit diagrams (SP) provided on the customer DVD
supplied with the device for the arrangement of components and interfaces, and for wiring.
Figure 5-14 Basic Line Module
