Cabinet Modules
5.1 Line Connection Modules
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
151
SCCR (short circuit current rating)
Minimum short-circuit current
5)
Current demand of contactors/circuit breakers and fans.
The specified power loss represents the maximum value at 100 % capacity utilization. The value in normal operation is
lower.
The cabinet height increases by 10" (250 mm) with degree of protection IP21, and by 16" (400 mm) with degrees of
protection IP23 (NEMA1 filtered), IP43, and IP54 (NEMA12 ventilated).
Ready to connect to parallel Line Modules.
5)
Minimum current required for reliable tripping of the contained protective devices.
