Electrical installation
4.5 Connections
Cabinet Modules NEMA
86 Manual, 04/2014, A5E03586450A
4.5.6
Connecting the motor cables
Preparatory steps
Install and secure the cabinet units properly.
Disconnect the cabinet units from the power supply.
Make sure that all the necessary safety measures have been taken at the installation
location.
WARNING
Risk of death from electric shock due to rotating permanent-magnet synchronous motors
As soon as the motor turns, a voltage is generated at the connection terminals that when
touched can result in death or serious injury.
Disconnect the motor when working on the converter.
If the cables to the motor cannot be disconnected, secure the motor to prevent
unintended rotating movements, e.g., by a holding brake.
Motor Modules Booksize Cabinet Kit
Table 4- 8 Motor connection, Motor Modules
Terminals
Technical specifications
DCP, DCN
DC power input
Voltage:
510 to 720 V DC
U2/T1, V2/T2, W2/T3
3 ph. AC power output
Voltage:
0 V 3 ph. AC to 0.72 x DC link voltage
Terminals:
AWG 10 to 4/0 (6 to 95 mm
2
) (→ see Technical specifications)
Motor Modules in chassis format
Table 4- 9 Motor connection, Motor Modules
Terminals
Technical specifications
DCP, DCN
DC power input
Voltage:
510 to 720 V DC
675 to 1035 V DC
U2/T1, V2/T2, W2/T3
3 ph. AC power output
Voltage:
0 V 3 ph. AC to 0.72 x DC link voltage
Connection:
M12 / 50 Nm for cable lugs in accordance with DIN 46234 or
DIN 46235
1)
1)
Dimensions for connecting alternative cable lugs, see Section "Cable lugs" in the section "Electri-
cal installation".
