8.27 L25, circuit breaker in withdrawable unit design
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
445
8.27
L25, circuit breaker in withdrawable unit design
Availability of option
This option is available for the following S120 Cabinet Modules:
Line Connection Modules
Description
The circuit breaker in slide-in design is available as an option for Line Connection Modules
with rated currents > 800 A. This breaker replaces the standard built-in circuit breaker.
The slide-in circuit-breaker features a visible isolating distance.
X50 "circuit breaker" checkback contact
Table 8- 45 Terminal block X50 "Circuit breaker" checkback contact
Terminal
Designation
1)
Technical specifications
1
NC
"Circuit breaker" checkback contacts
Max. load current: 3 A
Max. switching voltage: 250 V AC
2
NO
3
COM
Max. connectable cross-section #14 AWG (2.5 mm²)
1)
NC: normally-closed contact, NO: normally-open contact, COM: mid-position contact
Note
Additional information
Detailed and comprehensive instructions and information for the circuit breaker, as well as
the factory
-installed options, can be found in the associated operating instructions. These
operating instructions are available as additional documentation on the customer DVD
supplied with the device.
