Diagnostics
7.13 LEDs on the SMC30 Sensor Module
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
345
7.13
LEDs on the SMC30 Sensor Module
Table 7- 22 Meaning of the LEDs on the SMC30 Sensor Module
LED
Color
Status
Description
RDY
(READY)
--- Off The electronics power supply is missing or lies outside the permissible tolerance
range.
Green Continu-
ous light
The component is ready for operation and cyclic DRIVE-CLiQ communication is
taking place.
Orange Continu-
ous light
DRIVE-CLiQ communication is being established.
Red Continu-
ous light
At least one fault is present in this component.
Note:
LED is activated irrespective of any reconfiguring of the corresponding messages.
Green/
Red
Flashing
0.5 Hz
Firmware is being downloaded.
Flashing
2 Hz
Firmware download is being completed.
Waiting for POWER ON.
Green/
Orange
or
Red/
Orange
Flashing Detection of the component via LED is activated (p0144).
Note:
The two options depend on the LED status when component detection is activated
via p0144 = 1.
OUT > 5
V
- Off The electronics power supply is missing or lies outside the permissible tolerance
range.
Power supply ≤ 5 V.
Orange Continu-
ous light
The electronics power supply for the measuring system is available.
Measuring system supply > 5 V
Notice:
You must ensure that the connected encoder can be operated with a 24 V power
supply.
If an encoder that is designed for a 5 V supply is operated with a 24 V supply, this
can destroy the encoder electronics.
