8.11 K50, Sensor Module Cabinet-Mounted SMC30
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
377
8.11
K50, Sensor Module Cabinet-Mounted SMC30
8.11.1
General information
Availability of option
This option is available for the following S120 Cabinet Modules:
● Booksize Cabinet Kits
● Motor Modules in chassis format
Description
The SMC30 Sensor Module is used for determining the actual motor speed. The signals
coming from the rotary pulse encoder are converted here and made available to the closed-
loop controller via the DRIVE-CLiQ interface for evaluation purposes.
The following encoders can be connected to the SMC30 Sensor Module:
● TTL encoder
● HTL encoder
● SSI encoder
● KTY or PTC temperature sensor or bimetallic switch with NC contact
Table 8- 9 Connectable encoders with supply voltage
Encoder type
X520 (SUB-D)
X521 (terminal)
X531 (terminal)
Open-circuit moni-
toring
Remote sense
HTL bipolar 24 V
Yes
Yes
Yes
Yes
No
HTL unipolar 24 V
Yes
Yes
Yes
No
No
TTL bipolar 24 V
Yes
Yes
Yes
Yes
No
TTL bipolar 5 V Yes Yes Yes Yes To X520
TTL unipolar
No
No
No
No
No
SSI 24 V/5 V Yes Yes Yes No No
Table 8- 10 Maximum encoder cable length
Encoder type
Maximum signal cable length
TTL
330 ft (100 m)
HTL unipolar
330 ft (100 m)
HTL bipolar
980 ft (300 m)
SSI
330 ft (100 m)
