Page #208 background imageLoading...
Page #208 background image
Cabinet Modules
5.5 Booksize format Motor Modules
Cabinet Modules NEMA
208 Manual, 04/2014, A5E03586450A
Electrical options for Booksize Cabinet Kits
Component
Option
CBC10 Communication Board
G20
CBE20 Communication Board
G33
Safety license for 1 to 5 axes
K01 ... K05
AOP30 operator panel K08
SMC 10/20/30 Sensor Modules
K46, K48, K50
VSM10 Voltage Sensing Module Cabinet-Mounted K51
Additional SMC30 Sensor Module
K52
Auxiliary power supply 24 V DC
K73
Terminal Module for activating "Safe Torque Off" and "Safe STOP 1"
K82
Terminal Module TM54F
K87
Control Unit CU320-2 PROFIBUS
K90
Performance extension for CU320-2
K94
Control Unit CU320-2 PROFINET
K95
Motor reactor
L08/L09
DC interface including pre-charging input circuit of the associated DC-link
capacitance
L37
Motor reactor terminal connection
M51
5.5.4
Technical specifications
Table 5- 28 Technical specifications for Booksize Base Cabinet
Order no.
6SL3720-
1TX38-0AU3
1TX41-2AU3
Usable installation width
inch
mm
23.6
600
39.4
1000
Weight
(standard model) lb
kg
408
185
596
270
Dimensions
(standard model, IP20)
- width
- height
1)
- depth
- width
- height
1)
- depth
inch
inch
inch
mm
mm
mm
31.6
86.6
23.6
800
2200
600
47.2
86.6
23.6
1200
2200
600
1)
The cabinet height increases by 10" (250 mm) with degree of protection IP21, and by 16" (400
mm) for degrees of protection IP23 (NEMA1 filtered), IP43 and IP54 (NEMA12 ventilated).
