System overview
2.9 Overview of options
Cabinet Modules NEMA
34 Manual, 04/2014, A5E03586450A
Brief description of option
2 TM150 Temperature Sensor Modules
3 TM150 Temperature Sensor Modules
4 TM150 Temperature Sensor Modules
G56 Contactor monitoring
Safety license for 1 axis
Safety license for 2 axes
Safety license for 3 axes
Safety license for 4 axes
Safety license for 5 axes
AOP30 advanced operator panel installed in the cabinet door
Sensor Module Cabinet-Mounted SMC10
Sensor Module Cabinet-Mounted SMC20
Sensor Module Cabinet-Mounted SMC30
Voltage Sensing Module for determining the motor speed and the phase angle
Additional SMC30 Sensor Module
Auxiliary power supply 24 V DC
Auxiliary power generation in the Line Connection Module
Terminal module for controlling the "Safe Torque Off" and "Safe Stop 1" safety functions
Safe Brake Adapter SBA 230 V AC
Control Unit CU320-2 PROFIBUS
K94 Performance extension for CU320-2
Control Unit CU320-2 PROFINET
L08 Motor reactor
Two motor reactors connected in series
dv/dt filter plus voltage peak limiter
Line reactor not included in product package
Circuit breaker in withdrawable unit design
DC interface including pre-charging input circuit of the associated DC-link capacitance
Current transformer upstream of main switch
Line Connection Module for Active Line Modules
Line Connection Module for Basic Line Modules
Line Connection Module for Smart Line Modules
EMERGENCY OFF pushbutton installed in the cabinet door
Cabinet light with service socket
Cabinet anti-condensation heating
25 / 125 kW braking unit for line voltages of 380 to 480 V and 660 to 690 V
50 / 250 kW braking unit for line voltages of 380 to 480 V and 660 to 690 V
25 / 125 kW braking unit for line voltages of 500 to 600 V
50 / 250 kW braking unit for line voltages of 500 to 600 V
