Page #195 background image
Cabinet Modules
5.4 Active Line Modules including Active Interface Modules
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
195
Order no.
6SL3730-
7TE32-
1AU3
7TE32-
6AU3
7TE33-
8AU3
7TE35-
0AU3
Weight
(standard model) lb
kg
838
380
838
380
1169
530
1169
530
Frame size
FX + FI FX + FI GX + GI GX + GI
SCCR (short circuit current rating)
kA IC
65
65
65
65
Minimum short-circuit current
7)
A
3000
3000
8000
8000
1)
The base load current I
H DC
is based on a duty cycle of 150 % for 60 s or I
max DC
for 5 s with a duty cycle duration of
300 s.
2)
The current demand for the 400 V AC and 230 V AC auxiliary supplies is provided by the line supply input voltage.
3)
The specified power loss represents the maximum value at 100 % capacity utilization. The value in normal operation is
lower.
4)
Total sound pressure level of Active Interface Module and Active Line Module.
5)
Total of all motor cables and DC link. Longer cable lengths for specific configurations are available on request, see
SINAMICS - Low Voltage Configuration Manual on the customer DVD supplied with the device.
6
)
The cabinet height increases by 10" (250 mm) with degree of protection IP21, and by 16" (400 mm) with degrees of
protection IP23 (NEMA1 filtered), IP43, and IP54 (NEMA12 ventilated).
7)
Minimum current required for reliable tripping of the contained protective devices.
