System overview
2.1 Overview
Cabinet Modules NEMA
26 Manual, 04/2014, A5E03586450A
Figure 2-1 Example of a drive assembly with SINAMICS S120 Cabinet Modules for a multi-motor drive
The following table provides an overview of the voltage ranges and power ratings available
for the SINAMICS S120 Cabinet Modules:
Table 2- 1 Overview of voltage ranges and power ratings of the SINAMICS S120 Cabinet Modules
Supply
voltage
3 ph. AC
Input
current
DC link
voltage
DC
DC link
current
Output
current
Power
Line Connection
Modules
1)
380 ... 480 V
500 to 690 V
250 ... 3000 A
280 to 3000 A
Basic Line
Modules
1)
380 ... 480 V
500 to 690 V
365 ... 1630 A
260 to 1580 A
510 to 650 V
675 to 930 V
420 to 1880 A
300 to 1880 A
200 ... 900 kW
250 ... 1500 kW
Smart Line
Modules
1)
380 ... 480 V
500 to 690 V
463 ... 1430 A
463 ... 1430 A
510 to 650 V
675 to 930 V
550 to 1700 A
550 to 1700 A
250 ... 800 kW
450 ... 1400 kW
Active Line
Modules
1)
380 ... 480 V
500 to 690 V
210 ... 1405 A
575 ... 1270 A
570 to 720 V
750 to 1035 V
235 to 1574 A
644 to 1422 A
132 ... 900 kW
560 ... 1400 kW
Motor Modules
Booksize
(380 ... 480 V) 510 ... 720 V 11 ... 158 A 9 ... 132 A 5 ... 100 HP
4.8 ... 71 kW
Motor Modules
Chassis
1)
(380 ... 480 V)
(500 to 690 V)
510 ... 720 V
675 to 1035 V
252 to 1686 A
102 to 1524 A
210 to 1405 A
85 to 1270 A
150 ... 1000 HP
110 to 800 kW
75 to 1250 HP
75 to 1200 kW
Auxiliary Power
Supply Module
380 ... 690 V 125 ... 250 A
1)
The power range can be extended as required by connecting up to 4 identical modules in parallel.
