8.22 K95, CU320-2 PN Control Unit
Cabinet Modules NEMA
Manual, 04/2014, A5E03586450A
421
Figure 8-31 Interface X140 and measuring sockets T0 to T2 - CU320-2 PN (view from below)
Malfunctions or damage to the Option Board by pulling and pluging it during operation
Withdrawing and inserting the Option Board during operation can damage it or cause it to
malfunction.
• Only pull and plug the Option Board when the Control Unit is current-free.
