11.1.16 Functional Test of HFO+CMV Mode
Step 36 For the functional test set the following parameters in the HFO+CMV preview
mode
BPM .....................30
Ti ..........................1 sec
HFO Rate.............10Hz
PEEP....................4mbar
PIP .......................30 mbar
Delta P .................Not available in preview mode
FiO
2
......................21%
After pressing the confirm button the user will be presented with the
HFO + CMV screen.
Set a Delta P of 4mbar
