SLE SLE5000 - Actions after Connection to Patient in HFO+CMV; Ventilation Without a Flow Sensor Connected

Page 179 of 292
16.9.1 Actions After Connection to Patient in HFO+CMV
Step 4. The user can select which type of HFO activity is
required by pressing the HFO Activity Button on
the Mode panel.
Select the mode required and press the Return
Button.
Limiting controls in HFO+CMV
The user needs to be aware that the following controls interact.
The PIP and Delta P controls limit each other. This is to stop their combined
setting exceeding the maximum pressure that can be generated by the pneumatic
system.
Step 5. Adjust the Delta P parameter as required.
Step 6. The High and Low Pressure Alarm thresholds auto track the pressure waveform
by 10mbar. The alarm thresholds can be adjusted if required. The thresholds are
found in the pressure waveform window.
16.9.2 Ventilation Without a Flow Sensor Connected.
When the ventilator is used without the flow sensor connected, the user will have
to set the Cycle Fail Alarm.
Flow based functions, waveforms and loops will not be displayed.
High
Low
