Page 160 of 292
16.4 CMV Set-up
Step 1. From the Mode Select panel select CMV.
Step 2. Default parameters in the preview mode:
BPM .....................30
Ti ..........................0.4 sec
PEEP....................2mbar
PIP .......................10mbar
FiO
2
......................As per prescription
Step 3. Press the Confirm button to enter the CMV mode. The ventilator will
now start to ventilate at the set parameters.
The ventilator is now ready to be connected to the
patient under user supervision. Prior to and after
connection it is the users responsibility to adjust and
monitor the ventilation parameters to suit the patient’s
medical condition.
