23.3 Overview
23.3.1 Data and Pinout Description.
Data Format: RS232-C compatible, 19200 bps, 8 data bits, 1 stop bit, no parity.
The data output is a comma delimited ASCII text string terminated by carriage
return and linefeed (<CR>,<LF>). There is 1 second between the start of
consecutive text string transmissions.
RS232 Pinout: The RS232 interface connector pin assignments are as follows;
23.3.2 Cable
This pin assignment allows the ventilator to be connected directly to the RS232-C
serial port on a PC with a standard serial cable.
Pin Signal
1 DCD
2TXD
3RXD
4 DSR
5GND
6DTR
7CTS
8RTS
