12. Stage 1 Check List
The ventilator must pass all the test’s.
Pass Fail
Step 1: Complete power fail alarm test.
Audible alarm triggered and cancelled.
Step 2: Setting FiO
2
.
Measured value corresponds to set value.
Step 5: Oxygen alarm test.
High and Low alarms triggered.
Step 10: Function and alarm testing.
Test lung inflates.
Step 11: Function and alarm testing.
Apnoea alarm triggered after 20 seconds.
Step 12: Function and alarm testing.
Manual breath delivered.
Step 13: Function and alarm testing.
Apnoea alarm triggered after 10 seconds.
Step 15: Function and alarm testing.
continuing positive pressure alarm
is triggered after 10 seconds.
Step 19: Function and alarm testing.
A waveform appears in both waveform
windows.
Step 20: High pressure alarm.
Alarm triggered and cancelled.
Step 21: Low Pressure alarm.
Alarm triggered and cancelled.
Step 22: Breath Not Detected Alarm.
Alarm triggered and cancelled.
