13. Stage 2 check list
The ventilator must pass all the test’s.
Pass Fail
Step 44: CMV functional test.
ventilator is cycling, waveforms
appear and I:E ratio = 1:1.
Step 46: Wave shape modified.
Pressure wave modified.
Step 49: Waveform display synchronisation.
Waveforms should be displayed
starting at the left hand edge of
the window.
Step 50: Waveform display synchronisation.
Waveforms should be displayed
starting any where in the window.
Step 54: Wave shape modified by TTV.
Pressure wave modified.
Step 59: PSV functional test.
When the test lung is squeezed
that a waveform appears in the waveform
window. When the pressure is released
from the test lung that the ventilator provides
support by helping reinflate the test lung.
Step 61: PSV functional test.
After 10 seconds that the ventilator delivers
a backup breath and the visual and audible
Apnoea alarm is triggered.
Step 64: SIMV functional test.
The ventilator cycles, the cycle waveform
appears in the waveform windows, after
1 minute the BPM tot should read
20 BPM in the breath parameter window.
