11.2 Stage 2 Functional testing
The stage 2 testing routine must be carried out in conjunction with a stage 1
testing routine.
11.2.1 Functional Test of CMV Mode
Step 43 For the functional test set the following parameters in the CMV preview mode:
BPM..................... 30
Ti.......................... 1 sec
PEEP ................... 5mbar
PIP....................... 20 mbar
FiO
2
..................... 21%
After pressing the confirm button the user will be presented with the
CMV screen.
Check that:
TTV ..................... is set to OFF. (This button will not appear
when functional testing with no flow sensor fitted).
Stage 2 Functional Testing
